SKU:

787-1732

UPC:

MPN:

787-1732

Condition:

New

conformity marking:

CE

connection technology:

CAGE CLAMP

connection type 1:

Input/output

control deviation:

¤ 1 %

country of origin sales organisation germany:

CN

default setting:

DC 24 V

depth from upper edge of din rail:

99 mm / 3.898 inch

derating:

-4 %/K (> 45 C)

discharge current:

¤ 0.05 mA

efficiency typ:

91 % (230 VAC: 10 ADC)

fine stranded conductor:

0.08 2.5 mm / 28 12 AWG

fire load:

0.000 MJ

height:

165 mm / 6.496 inch

input current ii:

¤ 2 A (230 VAC): ¤ 4 A (115 VAC)

input voltage range:

AC 90 264 V: DC 125 375 V

inrush current:

¤ 18 A

internal fuse:

F 3.15 A / 250 VAC

isolation voltage pri gnd:

DC 2.2 kV

isolation voltage pri sec:

DC 4.242 kV

isolation voltage sec gnd:

DC 0.7 kV

mains failure hold up time:

10 ms (230 VAC)

mounting type:

DIN-35 rail || Screw mount

mtbf:

> 300,000 h (per IEC 61709)

nominal input voltage ui nom:

1 x AC 100 240 V

nominal mains frequency range:

47 63 Hz: 0 Hz

nominal output current io nom:

10 A (24 VDC: 110 240 VAC): 8 A (24 VDC: 100 240 VAC)

nominal output power:

240 W

nominal output voltage uo nom:

DC 24 V (SELV)

note conductor cross section:

12 AWG: THHN, THWN

open circuit proof:

Yes

operation status indicator:

Green LED (Uo)

output voltage range:

DC 22 26 V (adjustable)

overload behavior:

Constant power (in overload range: 1.05 1.4 x Io nom): Shutdown and automatic restart in the event of a short circuit

overvoltage category:

II

packaging type:

Box

parallel operation:

Yes

phases:

1

pollution degree:

2

power factor correction pfc:

Active

power loss pl:

¤ 38 W (230 VAC: 24 VDC: 10 A)

protection class:

I

protection type:

IP20 (per EN 60529)

recommended backup fusing:

Circuit breaker: B6, B10

relative humidity:

10 95 % (no condensation permissible)

required backup fusing:

An external DC fuse is required for the DC input voltage.

residual ripple:

¤ 200 mV (Peak-to-peak)

resistance to reverse feed:

¤ DC 30 V

series operation:

Yes, for 2 devices of the same type

short circuit protected:

Yes

signaling:

1 x LED DC OK (green)

solid conductor:

0.08 2.5 mm / 28 12 AWG

standards specifications:

EN 61204-3 || EN 60335-1 || EN 62368-1 || UL 60950-1 || UL 508

strip length:

6 7 mm / 0.24 0.28 inch

surrounding air temperature operation:

-20 60 C

surrounding air temperature storage:

-25 75 C

transient suppression primary:

Varistor

wago connector:

WAGO 236 Series

weight:

840.000 g

width:

70 mm / 2.756 inch
