WAGO 855-8001

(No reviews yet) Write a Review

Write a Review

×

WAGO 855-8001

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

855-8001

Condition:

New

cable length:

3 m

cable type:

Secondary side: 1 x 1.0 mm: flexible: with ferrule

conformity marking:

CE

connection technology:

IDC

continuous current max:

0.0833333333333333

country of origin sales organisation germany:

NL

depth:

23 mm / 0.906 inch

feedthrough for measurement conductor:

3 5 mm

fine stranded conductor:

2.5 6 mm / 14 10 AWG

fire load:

0.000 MJ

flammability class per ul94:

V2

fuse voltage path:

2 A: 450 V: F: 70 kA: 5 x 25 mm (WAGO 855-8020)

height:

59 mm / 2.323 inch

housing material:

PA 66

mounting type:

Insulation displacement connection (IDC) || Mounting on insulated round cable

note:

Spare fuse: WAGO 855-8020

operating altitude max:

2000 m

packaging type:

Box

rated voltage:

AC 400 V

relative humidity:

5 85 % (without condensation)

solid conductor:

2.5 6 mm / 14 10 AWG

standards specifications:

EN 60947-7-1

surrounding air temperature operation:

-5 55 C

surrounding air temperature storage:

-20 70 C

test voltage:

AC 3 kV: 50 Hz: 1 min

torque range:

1.5 2 Nm

usability:

Can be reused several times (max. 24 times)

voltage drop at output max:

¤ AC 0.5 V

weight:

25.900 g

width:

23 mm / 0.906 inch
