Wago 2091-1722/200-000/997-604 THR male header, 1.0 mm Ø solder pin angled, black Pack of 700

(No reviews yet) Write a Review
SKU:
2091-1722/200-000/997-604
Condition:
New
Availability:
Contact us for lead time
$583.80

Description

THR male header, 1.0 mm Ø solder pin angled, black

View AllClose

Additional Information

anti rotation protection:
Yes
color:
Black
CONNECTOR CONNECTION TYPE:
For PCB
CONTACT MATERIAL:
Electrolytic copper (ECu)
CONTACT PLATING:
Tin
CONTACT TYPE PLUGGABLE CONNECTOR:
Male connector/plug
COUNTRY OF ORIGIN VKORG GERMANY:
CN
CUSTOMS TARIFF NUMBER VKORG GERMANY:
85366990990
FIRE LOAD:
0.000 MJ
FLAMMABILITY CLASS PER UL94:
V0
INSULATION MATERIAL:
Polyphthalamide (PPA GF)
LEGEND RATINGS:
(III / 2) ‰™ Overvoltage category III / Pollution degree 2
LIMIT TEMPERATURE RANGE:
-60 €¦ +100 °C
LOCKING OF PLUG IN CONNECTION:
None
MATERIAL GROUP:
I
MEASUREMENT ERROR DEVIATION MAX FROM THE UPPER RANGE VALUE:
MEASUREMENT ERROR DEVIATION MAX OF THE UPPER RANGE VALUE 2=
MISMATING PROTECTION:
NoMOUNTING NOTE=
NOMINAL VOLTAGE II 2:
320 V
NOMINAL VOLTAGE III 3:
160 V
NOTE MATERIAL DATA:
Information on material data can be found here
NUMBER OF CONNECTION TYPES:
1
NUMBER OF LEVELS:
1
PCB CONTACT:
THR
PIN SPACING:
3.5 mm / 0.138 inches
PLATED THROUGH HOLE DIAMETER THR:
1.2 (+0.1) mm
PLUGGING WITHOUT LOSS OF PIN SPACING:
Yes
PRODUCT GROUP CODE:
26
RATED CURRENT:
0.416666666666667
RATED IMPULSE VOLTAGE III 2:
2.5 kV
RATED IMPULSE VOLTAGE III 3:
2.5 kV
RATED SURGE VOLTAGE II 2:
2.5 kV
RATED VOLTAGE III 2:
160 V
RATINGS PER:
IEC/EN 60664-1
REEL DIAMETER OF TAPE AND REEL PACKAGING:
380 mm
SAFETY INFORMATION 1:
The picoMAX® Pluggable Connection System includes connectors without breaking capacity in accordance with DIN EN 61984. When used as intended, these connectors must not be connected/disconnected when live or under load. The circuit design should ensu
SOLDER PIN DIAMETER:
1 mm
SOLDER PIN LENGTH:
2.4 mm
TAPE WIDTH:
24 mm
VARIABLE CODING:
Yes
WEIGHT:
678.500 g
WEIGHT OF INSULATION MATERIAL:
0.07 g
View AllClose
