Description
Overview
Abb
Switching Power Supplies, Cp-E Series
Item# 1Svr427036R0000 - Power Supply, 24Vdc, 20A, 1Ph, 480W Switching, Enclosed, 85-264Vac Input 123.6 Hx175 Wx123.6Mm D, Screw Term
Cp-E Series Information
- Output Voltages 5V, 12V, 24V, 48V Dc
- Adjustable Outputs
- High Efficiency Of Up To 90 Percent
- Open-Circuit, Overload, And Short Circuit Stable
- Low Power And Heating Dissipation
- Integrated Input Fuse
- Led'S For Status Indication
Specifications
Item Number: &Nbsp;
1Svr427036R0000
Upc: &Nbsp;
804325456258
Brand:
Abb
Item Category:
Power Supplies
Subcategory:
Switching
Series:
Cp-E
Power:
480 Watts
Nominal Input Vac:
120/240 Volts Ac
Input Vac:
115 To 230 Volts Ac
Input Frequency:
47 To 63 Hertz
Phase (Input):
1
Nominal Output Vdc:
24
Output Vdc:
24
Output Current:
20
Number Of Outputs:
1
Mounting:
Din
Enclosed:
Yes
Encapsulated:
No
Output Voltage Adj.:
Yes
Overvoltage Protection:
Yes
Overload Protection:
Yes
Short Circuit Protection:
Yes
Power Factor Correction:
Yes
Parallel Operation:
Yes
Remote Sensing:
No
Remote On/Off Control:
No
Efficiency %:
89 Percent
Operating Temperature:
-77 To 158 Degrees F
Approvals:
Ul508,Ul60950,Culus,Gost,Ccc,Ce
Rohs:
Yes
&Nbsp;&Nbsp;Net Weight:
5 Lb 1 Oz
&Nbsp;&Nbsp;Gross Weight:
5 Lb 1 Oz
