ABB 9T51B0108 Buck-Boost Transformer, 0.5Kva, Dual Voltage, NEMA 3R Enclosure
ABB
$473.02
(No reviews yet)
Write a Review
Write a Review
ABB
ABB 9T51B0108 Buck-Boost Transformer, 0.5Kva, Dual Voltage, NEMA 3R Enclosure
The ABB 9T51B0108 Buck-Boost Transformer is a versatile and efficient solution for adjusting supply voltage levels. With a capacity of 0.5Kva, this single-phase, dry-type distribution transformer is designed with dual voltage primary and secondary capabilities, allowing for a wide range of voltage combinations. Ideal for applications requiring minor voltage adjustments, it can effectively buck (lower) or boost (raise) the supply voltage by 5 to 27%. Housed in a NEMA 3R nonventilated weatherproof enclosure, it is suitable for both indoor and outdoor use. The transformer features an encapsulated copper core and coils, along with an integrated junction box that includes a ground lug for straightforward wiring. This design is particularly beneficial when connecting three units to form a 3-phase autotransformer. The improved termination spacing and ample wiring compartment provide flexibility in selecting various UL listed connectors for copper or aluminum cables. The ABB 9T51B0108 is available in both isolation and autotransformer types, and it meets RoHS compliance, as well as UL and cUL listings. Additionally, it is qualified to meet the seismic requirements of IEEE-693-2005, IBC-2021, and CBC 2022, ensuring reliability and safety in demanding environments.
- Input Voltage:
- 120x240
- Height:
- 8.38
- Enclosure:
- NEMA 3R
- Temperature Rating:
- 40
- Width:
- 6.88
- Standard:
- Yes
- Frequency Rating:
- 60
- Wattage:
- 0.5
- Output Voltage:
- 45650
- Insulation:
- IS-12
- Phase:
- 1
- Spec Sheet:
- View
