Abb
Ac Reversing Iec Contactors, Star Series
Item# Af16R-30-22-13 - Rev,3P,17A,100-250Vac/Dc,2/2
Star Series Information
- Af Contactors Can Manage Large Control Voltage Variations - One Coil Can Be Used For Different Control Voltages Used Worldwide Without Any Coil Change
- The Built-In N.C. Auxiliary Contact Is A Mirror Contact In Compliance With Annex F Of Iec 60947-4-1
- Af Contactors Have Built-In Surge Protection And Do Not Require Additional Surge Suppressors
- Only Four Coils Cover Control Voltages Between 24-500 V 50/60 Hz Or 20-500 V Dc
- Electronic Coil Interface Accepts A Wide Control Voltage Range
Specifications
Item Number: &Nbsp;
Af16R-30-22-13
Upc: &Nbsp;
804325865241
Brand:
Abb
Item Category:
Contactors
Subcategory:
Ac Reversing Iec
Series:
Star
Nominal Coil Voltage:
120 Vac;240 Vac;110 Vdc;240 Vdc
Coil Voltage:
100250Vacvdc
Coil Type:
Electronic
Poles:
3No
Auxiliary Contacts:
1No; 1Nc
Termination:
Screw
Max Hp 200/208V 3Ph:
5 Horsepower
Max Hp 230/240V 3Ph:
5 Horsepower
Max Hp 460/480V 3Ph:
10 Horsepower
Max Hp 575/600V 3Ph:
15 Horsepower
General Purpose (Ac1):
30 Amps
Approvals:
Culus
&Nbsp;&Nbsp;Net Weight:
5 Lb
