ABB CR463L60AJA Lighting Contactor-Open, 30A Capacity, 2-12 Poles, Electrically Held with Contact Position Indication and Easy Configuration Options

The ABB CR463L60AJA Lighting Contactor-Open is a versatile and reliable solution for managing lighting circuits. Designed with electrically held contactors, it supports a range of configurations with 30A capacity across 2 to 12 poles. The contactor features a contact position indication system, allowing users to easily determine when the contact is closed. With 74 different circuit combinations possible, it offers flexibility for various applications. The device includes convenient side access for field power wiring and a contact configuration indicator for easy monitoring. Its robust pole terminals can accommodate up to two #8 AWG wires, ensuring secure connections. The manual operator and fast, sure three-point mounting system make installation straightforward. Enclosed contacts provide resistance to contaminants, enhancing reliability. The contactor is equipped with combination slotted/#2 Phillips screws for ease of use. Power poles can be easily changed from normally open (NO) to normally closed (NC) by simply unlatching and rotating them 180°. Rated for a range of tasks, the power poles support 30A rated contacts, 15A motor rated, and A600 pilot duty rated applications. The easy-to-read rating label and auxiliary contacts, rated A600, are suitable for low-level circuits down to 12V, 5mA. Plug-in auxiliary contacts are NO when installed on the left side of the base and NC on the right, providing additional flexibility. The power terminals are designed to be finger and back-of-hand safe, ensuring user safety. The quick-view coil voltage and easy-change coil features contribute to the contactor's user-friendly design. Additionally, the low magnetic noise ensures quiet operation, making it an ideal choice for various lighting control needs.
