ABB CR463LB0AJA Lighting Contactor-Open, 30A Capacity, 2-12 Poles, Electrically Held with Contact Position Indication and Easy Configuration Options

The ABB CR463LB0AJA Lighting Contactor-Open is a versatile and reliable solution for managing lighting circuits. Designed with CR463L Electrically Held Contactors, it supports a range of configurations with 30A capacity across 2 to 12 poles. The contactor features a contact position indication system, allowing users to easily determine when the contact is closed by the protrusion of a button. With 74 different circuit combinations possible, it offers flexibility for various applications. The device includes convenient side access for field power wiring and a contact configuration indicator for easy monitoring. The standard base accommodates all pole configurations, and robust pole terminals can accept up to two #8 AWG wires, ensuring secure connections. The manual operator and fast, sure three-point mounting system make installation straightforward. Enclosed contacts provide resistance to contaminants, enhancing reliability. The combination of slotted and #2 Phillips screws facilitates easy assembly and maintenance. Power poles can be effortlessly changed from normally open (NO) to normally closed (NC) by simply unlatching and rotating them 180°. Rated for a range of tasks, the contactor supports 30A rated contacts, 15A motor rated, and A600 pilot duty rated applications. The easy-to-read rating label ensures clear identification of specifications. Auxiliary contacts, rated A600, are suitable for low-level circuits down to 12V, 5mA, and can be plugged in as NO on the left side of the base or NC on the right. Safety is prioritized with finger and back-of-hand safe power terminals, while the quick-view coil voltage and easy-change coil design simplify maintenance. The low magnetic noise of the contactor results in quiet operation, making it an ideal choice for environments where noise reduction is important.
