ABB FBV16TE020R 20A Mccb 1P 347V Fbv
ABB
$876.58
The ABB FBV16TE020R is a state-of-the-art 20A molded case circuit breaker (MCCB) designed for optimal performance and safety. Featuring a 1-pole configuration and rated for 347V, this breaker incorporates advanced design elements such as double-break rotary contact structures and ablative materials that enhance its interruption capabilities. Capable of handling fault currents up to 150kA, it offers high interrupting ratings, selective coordination, and current limitation to reduce arc flash energy. This model, part of the Record Plus½ series, comes without lugs (indicated by the 'R' suffix in the product number) but maintains compatibility with a range of internal accessories like auxiliary switches and shunt trips. Ideal for a variety of applications, it ensures robust protection and reliable performance, adhering to UL standards with a listing in UL file number E11592.
- Load Rating:
- HACR
- Interrupt Rating:
- 35kA@277 Vac
- Frame:
- FB 100
- Number Of Poles:
- 1
- Trip Type:
- LI
- Amperage Rating:
- 20A
- Connection:
- 14-10 AWG
- Brand Name:
- Record Plus
- Standard:
- E11592
- Spec Sheet:
- View
