ABB
Illuminated Pushbuttons, MODULAR Series
Item# MP3-62Y11L1 - Pushbutton, Mom, Ylw, Ext, 120V Direct, 22mm Mounting, LED, 1NO & 1NC Contact Blocks, Chrome Metal Bzl
MODULAR Series Information
- 22mm or 30mm Mounting Size
- Incandescent or LED Types
- Finger-Safe Screw Terminals
- NEMA 13,4X; IP66
- UL; CSA; IEC Approvals
- Can Be Used in Tough Environments
- Up to Six Contact Blocks on One Actuator
- Easy to Mount and Wire
Specifications
Item Number:
MP3-62Y11L1
UPC:
804325471374
Brand:
ABB
Item Category:
Switches
Subcategory:
Pushbutton Illuminated
Series:
MODULAR
Nominal Mounting Size:
22 MilliMeters
Operation:
Momentary
Contacts:
1NO; 1NC
Lens/Button Shape:
Round Extended
Lens/Button Color:
Yellow
Lamp Type:
LED
Nominal Lamp Voltage:
120 VAC
Illumination Circuit:
Full Voltage
Terminal Type:
Fingersafe Screw
Bezel:
Metal Round
Full Shroud:
No
Max Voltage:
600 VAC;600 VDC
Current (A):
10 Amps
IEC Rating:
IP66
NEMA Rating:
13;4X
Depth Behind Panel:
1.91 Inches
Approvals:
UL;CSA;IEC
H x W x D:
16 in x 1.69 in x 1.18 in
Net Weight:
2.6 OZ
Gross Weight:
2.6 OZ
