ABB

ABB mcb s500 1p k 1.1a s500-s800 mini circuit breakers S501-K1.1

(No reviews yet) Write a Review
SKU:
S501-K1.1
MPN:
S501-K1.1
Condition:
New
  • ABB mcb s500 1p k 1.1a s500-s800 mini circuit breakers S501-K1.1
  • ABB mcb s500 1p k 1.1a s500-s800 mini circuit breakers S501-K1.1
$228.45

Description

Overview

ABB

Miniature Circuit Breakers, S500 Series

Item# S501-K1.1 - CIRCUIT BREAKER, 1-POLE, 0.73-1.1A

S500 Series Information
  • Supplemental Protector
  • Use as Overcurrent Protection
  • UL 1077 - E167556
  • K Trip Characteristic
  • AC/DC Rated
The S500 high performance MCB offers a compact solution to circuit protection. The S500 devices are UL tested, current limiting, and DIN rail mounted. The S500 is available with application-specific trip characteristics to provide maximum circuit protection. The breakers offer thermal-magnetic trip protection according to the K tripping characteristic. Accessories such as auxiliary contacts and busbars are available to complete your installation.

  • 600Y/277 VAC, 690 VDC
  • 0.1 to 45 Amps
  • Adjustable Trip Unit
  • Multi-functional Terminals
  • Finger Safe Terminals

Specifications

Item Number:
S501-K1.1
UPC:
662019536392
Brand:
ABB
Item Category:
Circuit Breakers
Subcategory:
Miniature
Series:
S500
Poles:
1
Amps:
1.1
UL Standard:
1077
Trip Curve:
K
Terminal Type:
Screw
Max Voltage:
277 VAC;250 VDC
Shunt Trip:
No
Protection:
Supplemental
Auxiliary Switch:
Optional
Undervoltage Release:
No
Terminals Included:
Line / Load
Trip Unit:
Fixed Thermal / Fixed Magnetic
Mounting:
DIN Rail
Neutral Pole:
No
kAIC @ 240 VAC:
30
CSA Standard:
22.2
kAIC @ 277 VAC:
14
Alarm Switch:
Optional
Busbar:
Optional
Approvals:
UL;CSA
H x W x D:
3.64 in x .98 in x 3.62 in
  Net Weight:
1 lb
  Gross Weight:
1 lb
