ABB mcb s500 4p uc-k 45a s500-s800 mini circuit breakers S504UC-K45

(No reviews yet) Write a Review
SKU:
S504UC-K45
MPN:
S504UC-K45
Condition:
New
  • ABB mcb s500 4p uc-k 45a s500-s800 mini circuit breakers S504UC-K45
  • ABB mcb s500 4p uc-k 45a s500-s800 mini circuit breakers S504UC-K45
$1,314.25

Description

Overview

ABB

Miniature Circuit Breakers, S500UC Series

Item# S504UC-K45 - Circuit Breaker

S500UC Series Information
  • Fast Breaking Time (2.3 - 2.5 ms)
  • Wide Range of Accessories
  • Multi-Functional Terminals
  • High Breaking Capacity
  • Finger Safe Terminals
  • Adjustable Trip Unit
  • DIN Rail Mounting
The S500 high performance MCB offers a compact solution to circuit protection. The S500 devices are UL tested current limiting and DIN rail mounted. The S500 is available with application specific trip characteristics to provide maximum circuit protection. The breakers offer thermal-magnetic trip protection according to B and K characteristics.

Specifications

Item Number:
S504UC-K45
UPC:
662019534947
Brand:
ABB
Item Category:
Circuit Breakers
Subcategory:
Miniature
Series:
S500UC
Poles:
4
Amps:
45
UL Standard:
1077
Trip Curve:
K
kAIC @ 480 VAC:
14
Terminal Type:
Screw
Max Voltage:
600 VAC;600 VDC
Shunt Trip:
No
Protection:
Supplemental
Auxiliary Switch:
Optional
Undervoltage Release:
No
Terminals Included:
Line / Load
Trip Unit:
Fixed Thermal / Fixed Magnetic
Mounting:
DIN Rail
Neutral Pole:
No
CSA Standard:
22.2
kAIC @ 600 VAC:
6
kAIC @ 600 VDC:
30
Alarm Switch:
Optional
Busbar:
Optional
Approvals:
UL;CSA
H x W x D:
3.64 in x 3.93 in x 3.62 in
  Net Weight:
1 lb
  Gross Weight:
1 lb
