ABB TED134035 3 Pole 480Vac 35A Circuit Breaker with Thermal-Magnetic Trip - E150 Line, UL Listed for HID Applications, HACR Type
ABB
$2,193.91
The ABB TED134035 is a robust 3 Pole 480Vac 35A Circuit Breaker designed for reliable performance in demanding electrical environments. Featuring a Thermal-Magnetic Trip, this breaker is part of the E150 Line Circuit Breakers and is equipped with noninterchangeable trip functionality. It comes with Cu/Al load lugs, ensuring easy installation and compatibility. For applications requiring line lugs, simply add the suffix (WLÃ · to the product number. This breaker is UL listed for HID (high intensity discharge) applications and is classified as HACR type, except for the 10 ampere variant. Suitable for reverse feed, it offers a 60/75 C rating up to 100 amperes and a 75 C rating above 100 amperes, making it a versatile choice for various electrical systems.
- Amperage Rating:
- 35A
- Frame:
- E150
- Interrupt Rating:
- 10kA@125 Vdc / 10kA@250 Vdc / 10kA@500 Vdc / 14kA@600 Vac / 18kA@120 Vac / 18kA@120/240 Vac / 18kA@240 Vac / 18kA@277 Vac / 18kA@480 Vac
- Number Of Poles:
- 3
- Trip Type:
- LI
- Spec Sheet:
- View
