ABB TEYL3035B Teyx Circuit Breaker, 3-Pole, 35A, for Grounded 480Y/277 Vac Systems - Compact and Reliable with Quick-Make/Break Mechanism and Versatile Mounting Options
ABB
$2,283.00
The ABB TEYL3035B Teyx Circuit Breaker is a robust and compact solution designed for grounded 480Y/277 Vac systems. This 3-pole, 35A breaker is engineered with a one-inch wide per pole design, making it an ideal choice for space-constrained applications. Its bolt-on mounting base accessory enhances versatility, allowing it to function effectively as a lug-lug breaker. Safety and reliability are prioritized with features such as Quick-make / Quick-break mechanisms, common trip bars, and an easy-to-spot trip indication. The TEYL series offers flexibility with available auxiliary contact, shunt trip, undervoltage release, or bell alarm accessories for 2 and 3 pole versions. Whether for industrial or commercial use, the TEYL3035B ensures dependable performance and protection.
- Connection:
- #10-#4
- Application:
- Thermal Magnetic
- Interrupt Rating:
- 100kA@120/240 Vac,100kA@240 Vac,65kA@480Y/277 Vac, 42kA@125 Vdc,35kA@250 Vdc
- Standard:
- E11592
- Trip Type:
- LI
- Trip Range:
- Yes
- Amperage Rating:
- 35A
- Number Of Poles:
- 3
- Frame:
- TEYL
- Brand Name:
- TEY / Q-Line (Bolt-On)
- Sub Brand:
- TEYL
- Spec Sheet:
- View
