ABB THHQB32070 70A 22Ka 3P Circuit Breaker Compact, Reliable, and Customizable for Residential & Commercial Use
ABB
$1,019.32
The ABB THHQB32070 Thhqb Mcb 70A 22Ka 3P 240V is a robust and reliable circuit breaker designed for both residential and commercial applications. This Q Line circuit breaker is compact, with each pole measuring just one inch in width, and features a thermal-magnetic design for enhanced performance. The QB breakers are bolt-on versions, specifically crafted for secure attachment to the bus connections of load centers and lighting panels. Key features include Quick-make / Quick-break mechanisms, common trip bars, and an easy-to-spot trip indication, all of which contribute to its safety and reliability. Available in 1, 2, and 3 pole versions, this breaker can be customized with auxiliary contact and shunt trip accessories, and is suitable for use in HID applications. With a capacity of 70 Amps and a breaking capacity of 22Ka, the ABB THHQB32070 ensures dependable protection and efficient operation in various electrical systems.
- Interrupt Rating:
- 22kA@120 Vac / 22kA@120/240 Vac / 22kA@240 Vac
- Standard:
- E11592
- Number Of Poles:
- 3
- Brand Name:
- TEY / Q-Line (Bolt-On)
- Frame:
- Q-Line
- Amperage Rating:
- 70A
- Sub Brand:
- Q Line
- Load Rating:
- HACR
- Trip Range:
- Non-Interchangeable
- Application:
- Thermal Magnetic
- Trip Type:
- LI
- Spec Sheet:
- View
