ABB THHQC32020WL Circuit Breaker - 3-Pole, 20A, 240V, 22Ka Interrupting Capacity, Q Line Series
ABB
$855.06
The ABB THHQC32020WL Circuit Breaker is a robust and reliable solution for both residential and commercial electrical systems. This 3-pole, 20A, 240V circuit breaker is part of the Q Line series, known for its compact, one-inch wide per pole design. It features a thermal-magnetic mechanism that ensures efficient and safe operation. The QC version is designed for easy installation on a 35mm DIN rail, making it versatile for various applications. Safety is a priority with its Quick-make / Quick-break mechanisms, common trip bars, and clear trip indication. Additionally, the Q Line breakers can be customized with auxiliary contact and shunt trip accessories, providing flexibility to meet specific needs. With a high interrupting capacity of 22Ka, this circuit breaker guarantees dependable performance and protection for your electrical systems.
- Application:
- Thermal Magnetic
- Standard:
- E11592
- Trip Range:
- Non-Interchangeable
- Brand Name:
- Q-Line (Lug-Lug)
- Interrupt Rating:
- 22kA@120 Vac / 22kA@120/240 Vac / 22kA@240 Vac
- Trip Type:
- LI
- Amperage Rating:
- 20A
- Sub Brand:
- Q Line
- Load Rating:
- HACR
- Frame:
- Q-Line
- Number Of Poles:
- 3
- Spec Sheet:
- View
