ABB THQB1130 30A 10Ka 1P Circuit Breaker - Compact, Reliable, and Safe for Residential & Commercial Use
ABB
$78.75
The ABB THQB1130 Thqb Mcb 30A 10Ka 1P 120/240V is a compact, thermal-magnetic circuit breaker designed for both residential and commercial applications. Measuring just one inch wide per pole, this breaker is part of the Q Line series, known for its reliability and safety features. It is a bolt-on version, ideal for secure attachment to bus connections in load centers and lighting panels. The breaker boasts a Quick-make / Quick-break mechanism, common trip bars, and a clear trip indication for enhanced safety. Available in 1, 2, and 3 pole versions, it can be customized with auxiliary contact and shunt trip accessories, and is suitable for HID applications. With a capacity of 30 Amps and a 10Ka interrupting rating, the ABB THQB1130 ensures dependable performance in various electrical systems.
- Number Of Poles:
- 1
- Brand Name:
- TEY / Q-Line (Bolt-On)
- Trip Type:
- LI
- Connection:
- 14-8 kcmil / 12-8 kcmil
- Frame:
- Q-Line
- Interrupt Rating:
- 10kA@120 Vac / 10kA@120/240 Vac
- Standard:
- E11592
- Sub Brand:
- Q Line
- Load Rating:
- HACR
- Trip Range:
- Non-Interchangeable
- Amperage Rating:
- 30A
- Application:
- Thermal Magnetic
- Spec Sheet:
- View
