ABB THQC2115WL 2-Pole Circuit Breaker, 15A, 120/240V, 10Ka - Compact Thermal-Magnetic Design for Residential and Commercial Use

ABB THQC2115WL 2-Pole Circuit Breaker, 15A, 120/240V, 10Ka - Compact Thermal-Magnetic Design for Residential and Commercial Use

ABB
SKU:
THQC2115WL
|
UPC:
783164012521
Availability:
Commonly Stocked at Factory
$175.51
(No reviews yet) Write a Review
Condition:
New
Current Stock:
Description
The ABB THQC2115WL Circuit Breaker is a compact, thermal-magnetic device designed for both residential and commercial applications. This 2-pole, 15A breaker operates at 120/240V with a 10Ka interrupting capacity, ensuring robust performance and safety. Its one-inch width per pole allows for efficient use of space, while the lug-lug design is compatible with 35mm DIN rail mounting. Featuring Quick-make / Quick-break mechanisms, common trip bars, and easy-to-spot trip indication, this circuit breaker provides reliable protection and ease of use. Available in 1, 2, and 3 pole versions, it can also be equipped with auxiliary contact and shunt trip accessories for enhanced functionality.
Additional Information
Frame:
Q-Line
Standard:
E11592
Trip Type:
LI
Trip Range:
Non-Interchangeable
Application:
Thermal Magnetic
Number Of Poles:
2
Load Rating:
HACR
Amperage Rating:
15A
Interrupt Rating:
10kA@120 Vac / 10kA@120/240 Vac
Brand Name:
Q-Line (Lug-Lug)
Sub Brand:
Q Line
Spec Sheet:
View
