ABB THQC32025WL Circuit Breaker, 3-Pole, 25A, 240V, 10Ka - Compact Design for Residential and Commercial Use
ABB
$285.56
The ABB THQC32025WL Circuit Breaker is a robust and reliable solution for both residential and commercial electrical systems. This 3-pole, 25A, 240V circuit breaker is designed with a compact, one-inch wide per pole structure, making it ideal for space-constrained installations. Featuring a thermal-magnetic mechanism, it ensures efficient protection against overloads and short circuits. The QC series is a lug-lug version of the Q Line, compatible with 35mm DIN rail mounting for easy installation. Safety is prioritized with Quick-make / Quick-break mechanisms, common trip bars, and a clear trip indication for immediate fault identification. Available with optional auxiliary contact and shunt trip accessories, this circuit breaker offers versatility and enhanced functionality for various electrical applications.
- Amperage Rating:
- 25A
- Load Rating:
- HACR
- Interrupt Rating:
- 10kA@120 Vac / 10kA@120/240 Vac / 10kA@240 Vac
- Brand Name:
- Q-Line (Lug-Lug)
- Frame:
- Q-Line
- Trip Range:
- Non-Interchangeable
- Application:
- Thermal Magnetic
- Connection:
- 14-8 kcmil / 12-8 kcmil
- Standard:
- E11592
- Number Of Poles:
- 3
- Sub Brand:
- Q Line
- Trip Type:
- LI
- Spec Sheet:
- View
