ABB THQL22035 Circuit Breaker 2P 35A 240V 10Ka
ABB
$293.22
Q Line circuit breakers are one-inch wide per pole, compact, thermal-magnetic devices designed for residential and commercial applications in load centers or lighting panels. All Q Line circuit breakers feature Quick-make / Quick-break mechanisms, common trip bars, and easy to spot trip indication to ensure safety and reliability. Q Line breakers can be ordered with auxiliary contact and shunt trip accessories, and can be ordered for use in HID applications. The THQL22035 breaker features 2 poles, an ampere rating of 35 A, an interrupting rating of 10kAIC, and a voltage rating of 240V.
- Trip Type:
- LI
- Brand Name:
- Q-Line (Plug-In)
- Application:
- Thermal Magnetic
- Standard:
- E11592
- Load Rating:
- HACR
- Voltage Rating:
- 240 V
- Amperage Rating:
- 35 A
- Sub Brand:
- Q Line
- Trip Range:
- Non-Interchangeable
- Frame:
- Q-Line
- Interrupt Rating:
- 10kA@120 Vac / 10kA@120/240 Vac / 10kA@240 Vac
- Number Of Poles:
- 2
- Spec Sheet:
- View
