ABB TXQB32025 Circuit Breaker 3P 25A
ABB
$1,048.57
Q line circuit breakers are one-inch wide per pole, compact, thermal-magnetic devices designed for residential and commercial applications. The QB breakers are bolt-on versions of the Q Line used for bolting to the bus connections of load centers and lighting panels. All Q Line circuit breakers feature Quick-make / Quick-break mechanisms, common trip bars, and easy to spot trip indication to ensure safety and reliability. Q Line breakers are available in 1, 2, and 3 pole versions, can be ordered with auxiliary contact and shunt trip accessories, and can be ordered for use in HID applications. 2025 Amps 25 A
- Frame:
- Q-Line
- Standard:
- E11592
- Number Of Poles:
- 3
- Amperage Rating:
- 25A
- Sub Brand:
- Q Line
- Trip Type:
- LI
- Trip Range:
- Non-Interchangeable
- Application:
- Thermal Magnetic
- Interrupt Rating:
- 65kA@120 Vac / 65kA@120/240 Vac / 65kA@240 Vac
- Load Rating:
- HACR
- Brand Name:
- TEY / Q-Line (Bolt-On)
- Spec Sheet:
- View
