The Baumer FCE 200D1Y00 10151369 is a diffuse type fiber optic sensor with a coaxial fiber layout and a cylindrical threaded fiber optic head made of stainless steel. It features a sensing distance of 210 mm and an exit angle of 60°. The fiber optics are adjustable in length and the sensor operates within a temperature range of -30 to +70 °C. The head dimensions include a width/diameter of 3 mm and a length of 18 mm, with an M3 x 0.5 thread. The fiber optic cable, made of plastic with a PE jacket, measures 200 cm in length and has a cable jacket diameter of 1 mm. The bending radius for fixed installation is 15 mm. This model does not support an integrated or adaptable lens, nor is it compatible with infrared light at 1450 nm.
- Particular characteristics:
- Coaxial fiber layout
- Operating principle:
- Diffuse type
- Sensing distance Tw:
- 210 mm
- Fiber optic head:
- Cylindrical threaded
- Operating temperature:
- -30 +70 °C
- Exit angle:
- 60°
- Fiber optics can be shortened to length:
- Yes
- Integrated lens:
- No
- Adaptable lens:
- No
- Infrared light compatibility (1450 nm):
- NoDiameter Fiber=0.5 mm
- Width / diameter (head):
- 3 mm
- Height / length (head):
- 18 mm
- Material (head):
- Stainless steel
- Thread:
- M3 x 0.5
- Bending radius (fixed):
- 15 mm
- Cable jacket diameter:
- 1 mm
- Material cable jacket:
- PE
- Material (fiber optic cable):
- Plastic
- Length (fiber optic cable):
- 200 cm
- Datasheet:
- View
