The Baumer FSE 100A2001 10258822 is a through-beam type fiber optic sensor with a smooth sensing head. It features a cylindrical smooth fiber optic head made of aluminum, measuring 3 mm in width and 17 mm in length. The sensor operates within a temperature range of -25 to +70 °C and has an actual range of 500 mm. It is designed with a fixed bending radius of 7.5 mm and a mobile bending radius of 15 mm. The fiber optic cable, made of glass, is 100 cm long with a cross-section of 1 mm² and a PVC jacket with a diameter of 2.5 mm. This model does not support shortening of the fiber optics, nor does it include an integrated or adaptable lens. It is compatible with infrared light at 1450 nm and has an exit angle of 60°.
- Particular characteristics:
- Smooth sensing head
- Operating principle:
- Through-beam type
- Actual range Sb:
- 500 mm
- Fiber optic head:
- Cylindrical smooth
- Operating temperature:
- -25 +70 °C
- Exit angle:
- 60°
- Fiber optics can be shortened to length:
- No
- Integrated lens:
- No
- Adaptable lens:
- No
- Infrared light compatibility (1450 nm):
- YesWidth / diameter (head)=3 mm
- Height / length (head):
- 17 mm
- Material (head):
- Aluminum
- Bending radius (fixed):
- 7.5 mm
- Bending radius (mobile):
- 15 mm
- Cable jacket diameter:
- 2.5 mm
- Material cable jacket:
- PVC
- Fiber cross section:
- 1 mm²
- Material (fiber optic cable):
- Glass
- Length (fiber optic cable):
- 100 cm
- Datasheet:
- View
