The Baumer FUH 010A2002 10258838 is a diffuse type fiber optic sensor with a sensing distance of 35 mm. It features a cylindrical smooth fiber optic head made of chrome nickel steel, measuring 2 mm in width/diameter and 100 mm in height/length. The sensor operates within a temperature range of -25 to +120 °C and has an exit angle of 60°. It is compatible with infrared light at 1450 nm but does not allow for fiber optics to be shortened or the integration of adaptable lenses. The fiber optic cable, made of glass, has a cross section of 0.5 mm² and is encased in a stainless steel jacket with a diameter of 2 mm. The bending radius is fixed at 0 mm.
- Operating principle:
- Diffuse type
- Sensing distance Tw:
- 35 mm
- Fiber optic head:
- Cylindrical smooth
- Operating temperature:
- -25 +120 °C
- Exit angle:
- 60°
- Fiber optics can be shortened to length:
- No
- Integrated lens:
- No
- Adaptable lens:
- No
- Infrared light compatibility (1450 nm):
- YesWidth / diameter (head)=2 mm
- Height / length (head):
- 100 mm
- Material (head):
- Chrome nickel steel
- Bending radius (fixed):
- 0 mm
- Cable jacket diameter:
- 2 mm
- Material cable jacket:
- Stainless steel
- Fiber cross section:
- 0.5 mm²
- Material (fiber optic cable):
- Glass
- Datasheet:
- View
-
-
-
-
