Baumer IFBR 11N37T1/S14L-9 11014594
Baumer
$195.10
The Baumer IFBR 11N37T1/S14L-9 11014594 is a flush-mounted, hygienic design proximity sensor with a nominal sensing distance of 4 mm and adjustable hysteresis of 2 to 15% of Sr. It features a red LED output indicator and operates with a switching frequency of 1 kHz. The sensor supports a voltage supply range of 6 to 30 VDC, has a maximum no-load current consumption of 10 mA, and an NPN break function (NC) output circuit. The output current is 200 mA, reducing to less than 100 mA at cleaning temperatures. It includes short circuit and reverse polarity protection. The sensor's cylindrical smooth design is made from LCP for the sensing face and stainless steel 1.4404 (V4A) for the housing, measuring 11 mm in diameter and 60 mm in length. It connects via an M12 connector and operates within a temperature range of -40 to +80 °C, withstanding cleaning temperatures of 80 to 100 °C for up to 30 minutes per day. The sensor is rated IP 68/69K and proTect+ for high-level protection against ingress. It meets various regulatory approvals, including Ecolab, EHEDG, and multiple FDA and EC regulations.
- Mounting type:
- Flush
- Special type:
- Hygienic design
- Nominal sensing distance Sn:
- 4 mm
- Hysteresis:
- 2 15 % of Sr
- Output indicator:
- LED red
- Approvals/certificates:
- Ecolab Adapted from EHEDG REGULATION (EC) 1935/2004 REGULATION (EC) 2023/2006 REGULATION (EU) 1282/2011 FDA 21 CFR § 175.300 FDA 21 CFR § 177.2600 FCN 742
- Switching frequency:
- 1 kHz
- Voltage supply range +Vs:
- 6 30 VDC
- Current consumption max. (no load):
- 10 mA
- Output circuit:
- NPN break function (NC)
- Voltage drop Vd:
- <2 VDC
- Output current:
- 200 mA
- Output current (at cleaning temperature):
- < 100 mA
- Short circuit protection:
- Yes
- Reverse polarity protection:
- Yes
- Design:
- Cylindrical smooth
- Material (sensing face):
- LCP
- Housing material:
- Stainless steel 1.4404 (V4A)
- Dimension:
- 11 mm
- Housing length:
- 60 mm
- Connection types:
- Connector M12
- Operating temperature:
- -40 +80 °C
- Cleaning temperature:
- 80 +100 °C (30 min/day)
- Protection class:
- IP 68/69K & proTect+
- Datasheet:
- View
