The Baumer IFRD 08N17A1/S35L 10150429 is a quasi-flush, cylindrical threaded proximity sensor with a full metal housing designed for durability and reliability in demanding environments. It features a nominal sensing distance of 2 mm and a hysteresis range of 2 to 20% of Sr. Equipped with a 3-port LED red output indicator, it operates at a switching frequency of 150 Hz. The sensor supports a voltage supply range of 10 to 30 VDC and has a maximum no-load current consumption of 20 mA. Its output circuit is an NPN make function (NO) with a voltage drop of less than 2 VDC and an output current capacity of 200 mA. Safety features include short circuit and reverse polarity protection. The sensor's housing and sensing face are made of robust stainless steel 1.4404 (V4A), ensuring operation under static pressures of up to 20 bar. Dimensions include an 8 mm diameter and a 46 mm housing length, with an M8 connector for connectivity. It operates within a temperature range of -25 to +75 °C and offers high protection ratings of IP 68/67 for the sensing face and sensor respectively.
- Mounting type:
- Quasi-flush
- Special type:
- Full metal housing (DuroProx)
- Nominal sensing distance Sn:
- 2 mm
- Hysteresis:
- 2 20 % of Sr
- Output indicator:
- 3 port LED red
- Switching frequency:
- 150 Hz
- Voltage supply range +Vs:
- 10 30 VDC
- Current consumption max. (no load):
- 20 mA
- Output circuit:
- NPN make function (NO)
- Voltage drop Vd:
- <2 VDC
- Output current:
- 200 mA
- Short circuit protection:
- Yes
- Reverse polarity protection:
- Yes
- Design:
- Cylindrical threaded
- Material (sensing face):
- Stainless steel 1.4404 (V4A)
- Housing material:
- Stainless steel 1.4404 (V4A)
- Operating pressure static:
- < 20 bar
- Dimension:
- 8 mm
- Housing length:
- 46 mm
- Connection types:
- Connector M8
- Operating temperature:
- -25 +75 °C
- Protection class:
- IP 68/67 (sensing face/sensor)
- Datasheet:
- View
