Baumer IR18.P10S-F60.PO1Z.7CO/Z001_E009 11158437
Baumer
$148.90
The Baumer IR18.P10S-F60.PO1Z.7CO/Z001_E009 11158437 is a flush-mounted, marine-grade inductive sensor with a nominal sensing distance of 10 mm. It features a temperature drift of ±20%, hysteresis of 2 to 18% of Sr, and a switching frequency of 800 Hz. The sensor operates on a voltage supply range of 6 to 36 VDC, with a normal operating voltage of 24 VDC, and consumes a maximum of 12 mA with no load. It includes a PNP make function (NO) output circuit, supports an output current of 200 mA, and has built-in short circuit and reverse polarity protection. The sensor's cylindrical threaded design is made from brass nickel-plated and chromium-plated materials, with a PBT sensing face, and it connects via an M12 4-pin connector. It can operate in temperatures ranging from -40 to +75 °C and is rated IP 67 for protection against dust and water ingress. The sensor is also certified by DNV GL, ensuring compliance with marine industry standards.
- Mounting type:
- Flush
- Special type:
- Marine
- Nominal sensing distance Sn:
- 10 mm
- Temperature drift:
- ± 20 %
- Hysteresis:
- 2 18 % of Sr
- Output indicator:
- 3 port LED red
- Correction factor typ.:
- Mild steel 100 %, stainless steel 70 %, aluminum 40 %
- Approvals/certificates:
- DNV GL
- Switching frequency:
- 800 Hz
- Voltage supply range +Vs:
- 6 36 VDC
- Normal operating voltage:
- 24 VDC
- Current consumption max. (no load):
- 12 mA
- Output circuit:
- PNP make function (NO)
- Voltage drop Vd:
- <2 VDC
- Output current:
- 200 mA
- Short circuit protection:
- Yes
- Reverse polarity protection:
- Yes
- Design:
- Cylindrical threaded
- Material (sensing face):
- PBT
- Housing material:
- Brass nickel plated, chromium plated
- Dimension:
- 18 mm
- Housing length:
- 60 mm
- Connection types:
- Connector M12 4 pin
- Tightening torque max.:
- 40 Nm
- Operating temperature:
- -40 +75 °C
- Protection class:
- IP 67
- Datasheet:
- View
