Baumer IR30.P24S-N60.PV1Z.7BO 11174035
Baumer
$148.90
The Baumer IR30.P24S-N60.PV1Z.7BO 11174035 is a non-flush, cylindrical threaded proximity sensor with an enhanced distance feature from the GammaProx series. It offers a nominal sensing distance of 24 mm and operates with a temperature drift of ±10%. The sensor has a hysteresis range of 3 to 20% of Sr and includes a three-port LED red output indicator. It is designed to work effectively with different materials, having a correction factor of 100% for mild steel, 70% for stainless steel, and 50% for aluminum. The switching frequency is 500 Hz, and it supports a voltage supply range of 6 to 36 VDC with a maximum current consumption of 10 mA at no load. The output circuit is PNP complementary (NO/NC), and the sensor features a voltage drop of less than 2 VDC with an output current of 200 mA. It includes short circuit and reverse polarity protection. The sensor's housing is made of brass nickel-plated with a PBT sensing face, measuring 30 mm in diameter and 60 mm in length. It connects via an M12 connector and can withstand a tightening torque of up to 140 Nm. The operating temperature range is from -25 to +75 °C, and it is rated IP 67 for protection against dust and water ingress.
- Mounting type:
- Non-flush
- Special type:
- Enhanced distance (GammaProx)
- Nominal sensing distance Sn:
- 24 mm
- Temperature drift:
- ± 10 %
- Hysteresis:
- 3 20 % of Sr
- Output indicator:
- 3 port LED red
- Correction factor typ.:
- Mild steel 100 %, stainless steel 70 %, aluminum 50 %
- Switching frequency:
- 500 Hz
- Voltage supply range +Vs:
- 6 36 VDC
- Current consumption max. (no load):
- 10 mA
- Output circuit:
- PNP complementary (NO / NC)
- Voltage drop Vd:
- <2 VDC
- Output current:
- 200 mA
- Short circuit protection:
- Yes
- Reverse polarity protection:
- Yes
- Design:
- Cylindrical threaded
- Material (sensing face):
- PBT
- Housing material:
- Brass nickel plated
- Dimension:
- 30 mm
- Housing length:
- 60 mm
- Connection types:
- Connector M12
- Tightening torque max.:
- 140 Nm
- Operating temperature:
- -25 +75 °C
- Protection class:
- IP 67
- Datasheet:
- View
