Baumer MFFM 08P3424/PL/2000
Baumer
The Baumer MFFM 08P3424/PL/2000 is a high-precision sensor designed for industrial applications requiring accurate and reliable measurements. This model features a robust design suitable for challenging environments, ensuring durability and consistent performance. Ideal for automation systems, it offers excellent responsiveness and precision, making it a valuable component in quality control and process monitoring tasks.
- Scanning range Sd:
- 0.3 12 m
- Scanning range close limit Sdc:
- 0.3 12 m
- Scanning range far limit Sde:
- 0.3 12 m, (0.2 .18 m IO-Link)
- Repeat accuracy:
- < 4 mm
- Response time ton:
- < 40 ms, adjustable via IO-Link to 12 ms
- Release time toff:
- < 40 ms, adjustable via IO-Link to 12 ms
- Temperature drift:
- <± 10 mm (Full Scale)
- Power-up drift:
- < 2 mm compensated after 20 min.
- Adjustment:
- IO-Link
- Carrier frequency:
- 122 GHz
- Band width:
- 1 GHz
- Hysteresis typ.:
- 5 % (adjustable via IO-Link)
- Linearity error:
- < ± 20 mm (<1m) < ± 6 mm (>1m)
- Modulation type:
- FMCW
- Transmitting power (EIRP):
- < +20 dBm
- Aperture angle:
- 6 °
- MTTF:
- > 126 years
- Approvals/certificates:
- FCC / CFR-47 part 18 (USA) RSS-210 Issue 10 (Canada) EN 305 550-1 V.1.2.1 (European Union) EN 305 550-2 V.1.2.1 (European Union)
- Voltage supply range +Vs:
- 12 30 VDC
- Current consumption max. (no load):
- 220 mA
- Short circuit protection:
- Yes
- Reverse polarity protection:
- Yes, Vs to GND
- Output circuit:
- Current output / push-pull
- Output signal:
- 4 ... 20 mA / 20 ... 4 mA
- Output current:
- <100 mA
- Voltage drop Vd:
- <2.5 VDC
- Design:
- Cylindrical threaded
- Housing material:
- Brass nickel plated
- Material (sensing face):
- Plastics (PEI)
- Width / diameter:
- 30 mm
- Height / length:
- 107 mm
- Connection types:
- Connector M12
- Operating temperature:
- -40 +65 °C
- Storage temperature:
- -40 +85 °C
- Protection class:
- IP 68/69K
