Baumer

Baumer MY-COM A100/200 10221367

(No reviews yet) Write a Review
SKU:
10221367
MPN:
10221367
Condition:
New
Repeat accuracy:
0.001 mm
Activating force:
100 cN
Mech. pre-run / overrun:
- / 1,5 mm approx.
Measurement type:
Contact with medium
Direction of approach:
Frontal
DC voltage max.:
15 VDC
Switch. current DC max.:
2 mA
AC voltage max.:
24 VAC
Switch. current AC max.:
50 mA
Output circuit:
Break function (NC) mechanical
Activating pin:
Zirconium oxide ZrO2
Housing material:
Brass nickel plated
Dimension:
8 mm
Design:
Cylindrical threaded
Housing length:
20 mm
Connection types:
Cable, L=2 m
Operating temperature:
-20 … +75 °C
Protection class:
IP 50
Datasheet:
View
$354.00

Description

The Baumer MY-COM A100/200 10221367 is a high-precision mechanical contact sensor with a repeat accuracy of 0.001 mm and an activating force of 100 cN. It features a zirconium oxide activating pin and a brass nickel-plated housing, ensuring durability and resistance to wear. The sensor operates within a temperature range of -20 to +75 °C and is designed with a cylindrical threaded 8 mm diameter and a 20 mm housing length. It supports a maximum DC voltage of 15 VDC with a switching current of up to 2 mA, and a maximum AC voltage of 24 VAC with a switching current of up to 50 mA. The output circuit is a break function (NC) mechanical type. Connection is facilitated via a 2-meter cable, and the device is rated at IP 50 for protection against dust. Ideal for applications requiring precise measurement and reliable operation in challenging environments.
