The Baumer O200.SL.T-NV1T.72CV/F160_H006 11231180 is a high-performance light barrier designed for transparency object detection. It features a background position from 25 to 180 mm and a scanning range of 90% to 85% of the background position. The device ensures minimal signal attenuation of 10% and includes a green LED for power indication and a yellow LED for output status. It offers a sensing distance adjustment through qTeach and a focused distance of 160 mm. Equipped with suppression of reciprocal influence and a precise beam type, this sensor uses a pulsed red laser diode with a wavelength of 680 nm, classified as Laser class 1. It operates within a voltage supply range of 10 to 30 VDC, with typical current consumption of 10 mA at 24 VDC. The sensor supports both light and dark operating modes with NPN complementary output circuit and includes short circuit and reverse polarity protection. Its compact design measures 8 mm in width, 25.1 mm in height, and 15.8 mm in depth, housed in durable plastic with threaded stainless steel sleeves for easy mounting. The connection is facilitated by a 4-pin, 2-meter PVC cable. This device is IP 67 rated, ensuring operation in diverse environmental conditions ranging from -20 to +50 °C.
- Type:
- Light barrier
- Version:
- Transparency object detection
- Background position Sde:
- 25 180 mm
- Scanning range Sa:
- 90% ... 85% Sde
- Minimal signal attenuation:
- 10 %
- Power on indication:
- LED green
- Alignment / soiled lens indicator:
- Flashing output indicator
- Output indicator:
- LED yellow
- Sensing distance adjustment:
- qTeach
- Distance to focus:
- 160 mm
- Suppression of reciprocal influence:
- Yes
- Beam type:
- Point
- Alignment optical axis:
- < 1,5°Light source=Pulsed red laser diode
- Laser class:
- 1
- Wave length:
- 680 nm
- Voltage supply range +Vs:
- 10 30 VDC
- Current consumption max. (no load):
- 20 mA (@ 10 VDC)
- Current consumption typ.:
- 10 mA (@ 24 VDC)
- Voltage drop Vd:
- <2 VDC
- Output function:
- Light / dark operate
- Output circuit:
- NPN complementary
- Output current:
- 50 mA
- Short circuit protection:
- Yes
- Reverse polarity protection:
- Yes
- Width / diameter:
- 8 mm
- Height / length:
- 25.1 mm
- Depth:
- 15.8 mm
- Design:
- Rectangular
- Mechanical mounting:
- Threaded sleeves M3 (stainless steel)
- Housing material:
- Plastic (ASA, PMMA)
- Front (optics):
- PMMA
- Connection types:
- Cable 4 pin, 2 m
- Cable characteristics:
- PVC / PVC 4 x 0.08 mm²
- Protection class:
- IP 67
- Operating temperature:
- -20 +50 °C
