Baumer O300.DI.2-GLUBO.72N

Baumer O300.DI.2-GLUBO.72N

Baumer
SKU:
11246117
Availability:
Contact us to confirm availability and lead times.
$350.80
Condition:
New
Current Stock:
Description
The Baumer O300.DI.2-GLUBO.72N is a high-precision distance measuring sensor with a measuring distance of 20 to 300 mm and a measuring range of 280 mm. It features multiple adjustment options including Teach-in and IO-Link, and provides visual feedback through green and yellow LEDs for power and output status, respectively. The sensor offers repeat accuracy ranging from ? 150 to 4000 µm in Raw mode to ? 40 to 1000 µm in High Accuracy mode, and maintains a linearity error of ± 3% Mr. It utilizes a pulsed infrared diode with a wavelength of 860 nm and has response times as quick as < 1.5 ms in Raw mode, extending up to < 14 ms in High Accuracy mode. The device operates on a 12 to 30 VDC power supply, supports analog and push-pull / IO-Link output circuits, and includes safety features like short circuit and reverse polarity protection. Its compact, rectangular plastic housing measures 12.9 mm in width, 32.3 mm in height, and 23 mm in depth, and is designed to withstand harsh environments with an IP 67 protection rating. The sensor is suitable for a wide range of industrial applications, ensuring reliable performance in temperatures from -25 to +60 °C and resisting significant vibration and shock impacts.
Additional Information
Type:
Distance measuring
Measuring distance Sd:
20 … 300 mm
Measuring range Mr:
280 mm
Adjustment:
Teach-in and IO-Link
Power on indication:
LED green
Output indicator:
LED yellow
Repeat accuracy:
? 150 … 4000 µm (Raw) ? 120 … 3000 µm (High Speed) ? 80 … 2000 µm (Standard) ? 40 … 1000 µm (High Accuracy)
Linearity error:
± 3 % Mr
Beam type:
Point
Suppression of reciprocal influence:
Yes
Alignment optical axis:
< 2°
Temperature drift:
< 0,3 % Sde/KLight source=Pulsed infrared diode
Wave length:
860 nm
Response time / release time:
< 1.5 ms (Raw) < 2.25 ms (High Speed Mode) < 4.5 ms (Standard Mode) < 14 ms (High Accuracy Mode)
Voltage supply range +Vs:
12 … 30 VDC
Current consumption max. (no load):
30 mA
Voltage drop Vd:
<2 VDC
Output circuit:
Analog 0 ... 10 VDC Push-pull / IO-Link
Output current:
100 mA (push-pull)
Switching output:
Light operate, switchable
Short circuit protection:
Yes
Reverse polarity protection:
Yes, Vs to GND
Width / diameter:
12.9 mm
Height / length:
32.3 mm
Depth:
23 mm
Design:
Rectangular
Housing material:
Plastic (ASA, PMMA)
Front (optics):
PMMA
Connection types:
Connector M8 4 pin
Protection class:
IP 67
Operating temperature:
-25 … +60 °C
Storage temperature:
-40 … +70 °C
Vibration (sinusoidal):
IEC 60068-2-6:2008 10 g at f = 10 - 2000 Hz, duration 150 min per axis
Shock (semi-sinusoidal):
IEC 60068-2-27:2009 50 g / 11 ms, 10 impulses per axis and direction
