Baumer O300.GL-GW1J.72N 11171741
Baumer
The Baumer O300.GL-GW1J.72N 11171741 is a high-precision background suppression sensor with a sensing distance ranging from 30 to 250 mm and a repeat accuracy of less than 0.1 mm at laser focus. It features a pulsed red laser diode light source, with a wavelength of 656 nm and laser class 1, ensuring safe operation. The sensor includes both LED green power indication and LED yellow light indication for clear status visibility. It offers flexible sensing distance adjustment through Teach-in and IO-Link, and is equipped with a push-pull output circuit capable of handling 100 mA output current. The sensor's robust design includes a plastic housing made of ASA and PMMA, with an IP 67 protection class, making it suitable for challenging environments. It operates within a voltage supply range of 11 to 30 VDC and has built-in short circuit and reverse polarity protection. The compact dimensions (12.9 mm width, 32.3 mm height, 23 mm depth) and an M8 4-pin connector ensure easy integration into various applications.
- Type:
- Background suppression
- Sensing distance Tw:
- 30 250 mm
- Sensing range Tb:
- 15 250 mm
- Repeat accuracy:
- < 0.1 mm at laser focus
- Power on indication:
- LED green
- Light indicator:
- LED yellow
- Sensing distance adjustment:
- Teach-in and IO-Link
- Distance to focus:
- 80 mm
- Suppression of reciprocal influence:
- Yes
- Alignment optical axis:
- < 2°Light source=Pulsed red laser diode
- Laser class:
- 1
- Wave length:
- 656 nm
- Response time / release time:
- < 0.25 ms
- Voltage supply range +Vs:
- 11 30 VDC
- Current consumption max. (no load):
- 30 mA
- Current consumption typ.:
- 25 mA
- Voltage drop Vd:
- <2.5 VDC
- Output function:
- Light / dark operate
- Output circuit:
- Push-pull
- Output current:
- 100 mA
- Short circuit protection:
- Yes
- Reverse polarity protection:
- Yes
- Width / diameter:
- 12.9 mm
- Height / length:
- 32.3 mm
- Depth:
- 23 mm
- Design:
- Rectangular
- Housing material:
- Plastic (ASA, PMMA)
- Front (optics):
- PMMA
- Connection types:
- Connector M8 4 pin
- Protection class:
- IP 67
- Operating temperature:
- -10 +60 °C
- Datasheet:
- View
