The Baumer O300.GR-PV1T.72N 11135881 is a high-performance sensor with background suppression and a sensing distance ranging from 30 to 300 mm. It features a pulsed red LED light source with a wavelength of 630 nm and a quick response time of less than 1 ms. The sensor is equipped with LED indicators for power (green) and operation status (yellow), and offers easy distance adjustment via qTeach. It supports a voltage supply range of 10 to 30 VDC and has a maximum current consumption of 45 mA. The output function can operate in light or dark conditions with PNP complementary output circuit and a maximum output current of 100 mA. It includes safety features such as short circuit and reverse polarity protection. The sensor's compact, rectangular design measures 12.9 mm in width, 32.3 mm in height, and 23 mm in depth, with a durable plastic housing made of ASA and PMMA. It is designed for reliable operation in harsh environments with an IP 67 protection rating and an operating temperature range of -25 to +60 °C. The sensor connects via an M8 4-pin connector, ensuring easy integration into various applications.
- Type:
- Background suppression
- Sensing distance Tw:
- 30 300 mm
- Sensing range Tb:
- 15 300 mm
- Power on indication:
- LED green
- Light indicator:
- LED yellow
- Sensing distance adjustment:
- qTeach
- Suppression of reciprocal influence:
- Yes
- Alignment optical axis:
- < 2°Light source=Pulsed red LED
- Wave length:
- 630 nm
- Response time / release time:
- < 1 ms
- Voltage supply range +Vs:
- 10 30 VDC
- Current consumption max. (no load):
- 45 mA
- Current consumption typ.:
- 30 mA
- Voltage drop Vd:
- <3 VDC
- Output function:
- Light / dark operate
- Output circuit:
- PNP complementary
- Output current:
- 100 mA
- Short circuit protection:
- Yes
- Reverse polarity protection:
- Yes
- Width / diameter:
- 12.9 mm
- Height / length:
- 32.3 mm
- Depth:
- 23 mm
- Design:
- Rectangular
- Housing material:
- Plastic (ASA, PMMA)
- Front (optics):
- PMMA
- Connection types:
- Connector M8 4 pin
- Protection class:
- IP 67
- Operating temperature:
- -25 +60 °C
- Datasheet:
- View
