The Baumer O300.RP-NV1T.72N 11110447 is a retro-reflective sensor equipped with a pulsed PinPoint LED light source, offering a nominal range of 6 meters and an actual range of 5 meters. It features a polarization filter and suppression of reciprocal influence for enhanced performance. The sensor has a quick response time of less than 0.49 ms and operates with a voltage supply range of 10 to 30 VDC. It includes a yellow LED light indicator for operation status and a green LED for power indication. Sensitivity can be adjusted via qTeach. The sensor supports both light and dark operating modes with NPN complementary output circuit and can handle an output current of 100 mA. It is designed with a rectangular, plastic housing (ASA, PMMA) and a PMMA front optics. Dimensions are 12.9 mm in width, 32.3 mm in height, and 23 mm in depth. It connects via an M8 4-pin connector and operates within a temperature range of -25 to +60 °C. The sensor is IP 67 rated, ensuring protection against dust and water ingress, and includes features like short circuit and reverse polarity protection.
- Type:
- Retro-reflective sensor
- Light source:
- Pulsed PinPoint LED
- Actual range Sb:
- 5 m
- Nominal range Sn:
- 6 m
- Polarization filter:
- Yes
- Light indicator:
- LED yellow
- Power on indication:
- LED green
- Sensitivity adjustment:
- qTeach
- Wave length:
- 630 nm
- Suppression of reciprocal influence:
- Yes
- Alignment optical axis:
- < 2°
- Response time / release time:
- < 0.49 ms
- Voltage supply range +Vs:
- 10 30 VDC
- Current consumption max. (no load):
- 35 mA
- Current consumption typ.:
- 25 mA
- Voltage drop Vd:
- <3 VDC
- Output function:
- Light / dark operate
- Output circuit:
- NPN complementary
- Output current:
- 100 mA
- Short circuit protection:
- Yes
- Reverse polarity protection:
- Yes
- Width / diameter:
- 12.9 mm
- Height / length:
- 32.3 mm
- Depth:
- 23 mm
- Design:
- Rectangular
- Housing material:
- Plastic (ASA, PMMA)
- Front (optics):
- PMMA
- Connection types:
- Connector M8 4 pin
- Operating temperature:
- -25 +60 °C
- Protection class:
- IP 67
