The Baumer O300.RR-PV1Z.72N is a retro-reflective sensor equipped with a pulsed red LED light source and a polarization filter. It offers a nominal range of 5 meters and an actual range of 4 meters. This sensor features a quick response time of less than 0.49 ms and operates with a voltage supply range of 10 to 30 VDC. It includes a yellow LED light indicator for operation and a green LED for power status. The sensor does not require sensitivity adjustments and is designed to suppress reciprocal influence. It has a maximum current consumption of 35 mA and a typical consumption of 25 mA. The output function can operate in light or dark conditions with a PNP complementary output circuit and supports a maximum output current of 100 mA. It includes short circuit and reverse polarity protection. The sensor's compact, rectangular housing is made from durable plastic materials (ASA, PMMA) with a PMMA front optics. It connects via an M8 4-pin connector and is suitable for operating temperatures ranging from -25 to +60 °C. The device is IP 67 rated, ensuring protection against dust and water ingress.
- Type:
- Retro-reflective sensor
- Light source:
- Pulsed red LED
- Actual range Sb:
- 4 m
- Nominal range Sn:
- 5 m
- Polarization filter:
- Yes
- Light indicator:
- LED yellow
- Power on indication:
- LED green
- Sensitivity adjustment:
- No
- Wave length:
- 630 nm
- Suppression of reciprocal influence:
- Yes
- Alignment optical axis:
- < 2°
- Response time / release time:
- < 0.49 ms
- Voltage supply range +Vs:
- 10 30 VDC
- Current consumption max. (no load):
- 35 mA
- Current consumption typ.:
- 25 mA
- Voltage drop Vd:
- <3 VDC
- Output function:
- Light / dark operate
- Output circuit:
- PNP complementary
- Output current:
- 100 mA
- Short circuit protection:
- Yes
- Reverse polarity protection:
- Yes
- Width / diameter:
- 12.9 mm
- Height / length:
- 32.3 mm
- Depth:
- 23 mm
- Design:
- Rectangular
- Housing material:
- Plastic (ASA, PMMA)
- Front (optics):
- PMMA
- Connection types:
- Connector M8 4 pin
- Operating temperature:
- -25 +60 °C
- Protection class:
- IP 67
