The Baumer O300.TI-ZZZZ.72N 11209573 is a through beam sensor designed as an emitter. It features a pulsed infrared diode light source with a wavelength of 850 nm and an alignment optical axis of less than 2°. The sensor has an actual range of 10 m and a nominal range of 15 m. It includes a green LED for power indication and operates within a voltage supply range of 10 to 30 VDC. The sensor consumes a maximum of 40 mA with no load and typically 30 mA. It offers reverse polarity protection and is housed in a rectangular, plastic body (ASA, PMMA) with PMMA optics. Dimensions are 12.9 mm in width, 32.3 mm in length, and 23 mm in depth. It connects via an M8 4-pin connector and operates in temperatures ranging from -25 to +60 °C. The sensor is IP 67 rated for protection against dust and water ingress.
- Type:
- Through beam sensor
- Emitter / receiver:
- Emitter
- Light source:
- Pulsed infrared diode
- Actual range Sb:
- 10 m
- Nominal range Sn:
- 15 m
- Power on indication:
- LED green
- Wave length:
- 850 nm
- Alignment optical axis:
- < 2°
- Voltage supply range +Vs:
- 10 30 VDC
- Current consumption max. (no load):
- 40 mA
- Current consumption typ.:
- 30 mA
- Reverse polarity protection:
- Yes
- Width / diameter:
- 12.9 mm
- Height / length:
- 32.3 mm
- Depth:
- 23 mm
- Design:
- Rectangular
- Housing material:
- Plastic (ASA, PMMA)
- Front (optics):
- PMMA
- Connection types:
- Connector M8 4 pin
- Operating temperature:
- -25 +60 °C
- Protection class:
- IP 67
- Datasheet:
- View
