Baumer O330.EP-NDNVZ.72ZV/H006
Baumer
The Baumer O330.EP-NDNVZ.72ZV/H006 is a through beam sensor designed for precise object detection with a receiver component. It offers an actual range of 10 meters and a nominal range of 12 meters. The sensor features a flashing output indicator for alignment or soiled lens detection, and LED indicators for power status and output signaling. It operates without sensitivity adjustment and includes suppression of reciprocal influence to prevent interference from other devices. The response time is less than 0.8 ms, ensuring quick reactions. It supports a voltage supply range of 10 to 30 VDC and has a low current consumption with a maximum of 50 mA and a typical value of 25 mA. The output function can be set to light or dark operate, and it includes NPN complementary output circuit with a maximum output current of 100 mA. Safety features include short circuit and reverse polarity protection. The sensor's compact design measures 11 mm in width, 32 mm in height, and 21 mm in depth, with a rectangular shape and threaded sleeves M3 for easy mounting. It is constructed from durable plastic materials like ABS, ASA, and PMMA, with a PMMA front optics. The connection is facilitated by a 4-pin, 2-meter PVC cable. It operates within a temperature range of -25 to +55 °C and is rated IP 67 for protection against dust and water ingress, making it suitable for a variety of industrial environments. The storage temperature range is -40 to +70 °C.
- Type:
- Through beam sensor
- Emitter / receiver:
- Receiver
- Actual range Sb:
- 10 m
- Nominal range Sn:
- 12 m
- Alignment / soiled lens indicator:
- Flashing output indicator
- Output indicator:
- LED yellow
- Power on indication:
- LED green
- Sensitivity adjustment:
- No
- Suppression of reciprocal influence:
- Yes
- Response time / release time:
- < 0.8 ms
- Voltage supply range +Vs:
- 10 30 VDC
- Current consumption max. (no load):
- 50 mA
- Current consumption typ.:
- 25 mA
- Voltage drop Vd:
- <2 VDC
- Output function:
- Light / dark operate
- Output circuit:
- NPN complementary
- Output current:
- 100 mA
- Short circuit protection:
- Yes
- Reverse polarity protection:
- Yes
- Width / diameter:
- 11 mm
- Height / length:
- 32 mm
- Depth:
- 21 mm
- Design:
- Rectangular
- Mechanical mounting:
- Threaded sleeves M3 (brass)
- Housing material:
- Plastic (ABS, ASA, PMMA)
- Front (optics):
- PMMA
- Connection types:
- Cable 4 pin, 2 m
- Cable characteristics:
- PVC / PVC 4 x 0.14 mm²
- Operating temperature:
- -25 +55 °C
- Protection class:
- IP 67
- Storage temperature:
- -40 +70 °C
