The Baumer O330.RP-GDZZZ.72N/H006 is a retro-reflective sensor equipped with a pulsed PinPoint LED light source, offering a nominal range of 6 meters and an actual range of 5 meters. It features a polarization filter and a flashing output indicator for alignment or soiled lens detection. The sensor includes a yellow LED output indicator and a green LED for power on indication. With a wavelength of 634 nm and equipped with suppression of reciprocal influence, it ensures reliable operation. The alignment optical axis is under 1.5°, and it has a quick response time of less than 0.5 ms. Operating on a voltage supply range of 10 to 30 VDC, it has a maximum no-load current consumption of 50 mA and a typical consumption of 25 mA. The output function is dark operate with a push-pull output circuit and a maximum output current of 100 mA. It includes safety features such as short circuit and reverse polarity protection. The sensor's compact design measures 11 mm in width, 32 mm in height, and 21 mm in depth, with a rectangular shape and threaded sleeves M3 for mechanical mounting. The housing is made of durable plastic materials like ABS, ASA, and PMMA, with a PMMA front optics. It connects via an M8 4-pin connector and operates within a temperature range of -25 to +55 °C, boasting an IP 67 protection class for robust performance in various environments. For more detailed information, refer to the datasheet available [here](https://www.baumer.com/medias/__secure__/Baumer_O330.RP-GDZZZ.72N-H006_EN_20231002_DS.pdf?mediaPK=9104002121758).
- Type:
- Retro-reflective sensor
- Light source:
- Pulsed PinPoint LED
- Actual range Sb:
- 5 m
- Nominal range Sn:
- 6 m
- Polarization filter:
- Yes
- Alignment / soiled lens indicator:
- Flashing output indicator
- Output indicator:
- LED yellow
- Power on indication:
- LED green
- Wave length:
- 634 nm
- Suppression of reciprocal influence:
- Yes
- Alignment optical axis:
- < 1,5°
- Response time / release time:
- < 0.5 ms
- Voltage supply range +Vs:
- 10 30 VDC
- Current consumption max. (no load):
- 50 mA
- Current consumption typ.:
- 25 mA
- Voltage drop Vd:
- <2 VDC
- Output function:
- Dark operate
- Output circuit:
- Push-pull
- Output current:
- 100 mA
- Short circuit protection:
- Yes
- Reverse polarity protection:
- Yes
- Width / diameter:
- 11 mm
- Height / length:
- 32 mm
- Depth:
- 21 mm
- Design:
- Rectangular
- Mechanical mounting:
- Threaded sleeves M3 (brass)
- Housing material:
- Plastic (ABS, ASA, PMMA)
- Front (optics):
- PMMA
- Connection types:
- Connector M8 4 pin
- Operating temperature:
- -25 +55 °C
- Protection class:
- IP 67
- Storage temperature:
- -40 +70 °C
