Baumer O500.RP-NV1T.72CU 11096101
Baumer
$190.90
The Baumer O500.RP-NV1T.72CU 11096101 is a retro-reflective sensor equipped with a pulsed PinPoint LED light source, offering a nominal range of 8 meters and an actual range of 7.5 meters. It features a polarization filter and operates with a wavelength of 630 nm. The sensor includes a yellow LED light indicator for operation and a green LED for power status. It is designed with qTeach for easy sensitivity adjustment and has a response time of less than 0.49 ms. The sensor supports a voltage supply range of 10 to 30 VDC and has a typical current consumption of 30 mA. It offers both light and dark operating modes with NPN complementary output circuit and can handle an output current of up to 100 mA. The device is protected against short circuits and reverse polarity, ensuring reliable operation. Its compact, rectangular plastic housing measures 18 mm in width, 45 mm in length, and 32 mm in depth, and is made from durable ASA and PMMA materials. The sensor is equipped with a 4-pin, 2-meter cable for connectivity and operates within a temperature range of -25 to +60 °C. It is rated IP 67 for protection against dust and water ingress.
- Type:
- Retro-reflective sensor
- Light source:
- Pulsed PinPoint LED
- Actual range Sb:
- 7.5 m
- Nominal range Sn:
- 8 m
- Polarization filter:
- Yes
- Light indicator:
- LED yellow
- Power on indication:
- LED green
- Sensitivity adjustment:
- qTeach
- Wave length:
- 630 nm
- Suppression of reciprocal influence:
- Yes
- Alignment optical axis:
- < 1°
- Response time / release time:
- < 0.49 ms
- Voltage supply range +Vs:
- 10 30 VDC
- Current consumption max. (no load):
- 40 mA
- Current consumption typ.:
- 30 mA
- Voltage drop Vd:
- <3 VDC
- Output function:
- Light / dark operate
- Output circuit:
- NPN complementary
- Output current:
- 100 mA
- Short circuit protection:
- Yes
- Reverse polarity protection:
- Yes
- Width / diameter:
- 18 mm
- Height / length:
- 45 mm
- Depth:
- 32 mm
- Design:
- Rectangular
- Housing material:
- Plastic (ASA, PMMA)
- Front (optics):
- PMMA
- Connection types:
- Cable 4 pin, 2 m
- Operating temperature:
- -25 +60 °C
- Protection class:
- IP 67
- Datasheet:
- View
