The Baumer O500.RP-PV1T.72O 11096094 is a retro-reflective sensor equipped with a pulsed PinPoint LED light source, offering a nominal range of 8 meters and an actual range of 7.5 meters. It features a polarization filter and a wavelength of 630 nm, ensuring precise detection with minimal reciprocal influence. The sensor includes a yellow LED light indicator for operation status and a green LED for power indication. It is designed with qTeach for easy sensitivity adjustment and has a fast response time of less than 0.49 ms. The sensor operates on a voltage supply range of 10 to 30 VDC and includes both short circuit and reverse polarity protection. It supports light/dark operate output functions with a PNP complementary output circuit and can handle an output current of up to 100 mA. The compact, rectangular housing is made from durable plastic materials (ASA, PMMA) with a PMMA front optics, and it connects via an M12 4-pin connector. Suitable for operating temperatures ranging from -25 to +60 °C, the sensor is IP 67 rated for excellent protection against dust and water ingress.
- Type:
- Retro-reflective sensor
- Light source:
- Pulsed PinPoint LED
- Actual range Sb:
- 7.5 m
- Nominal range Sn:
- 8 m
- Polarization filter:
- Yes
- Light indicator:
- LED yellow
- Power on indication:
- LED green
- Sensitivity adjustment:
- qTeach
- Wave length:
- 630 nm
- Suppression of reciprocal influence:
- Yes
- Alignment optical axis:
- < 1°
- Response time / release time:
- < 0.49 ms
- Voltage supply range +Vs:
- 10 30 VDC
- Current consumption max. (no load):
- 40 mA
- Current consumption typ.:
- 30 mA
- Voltage drop Vd:
- <3 VDC
- Output function:
- Light / dark operate
- Output circuit:
- PNP complementary
- Output current:
- 100 mA
- Short circuit protection:
- Yes
- Reverse polarity protection:
- Yes
- Width / diameter:
- 18 mm
- Height / length:
- 45 mm
- Depth:
- 32 mm
- Design:
- Rectangular
- Housing material:
- Plastic (ASA, PMMA)
- Front (optics):
- PMMA
- Connection types:
- Connector M12 4 pin
- Operating temperature:
- -25 +60 °C
- Protection class:
- IP 67
