The Baumer O500.RR-GL1Z.72O 11096090 is a retro-reflective sensor equipped with a pulsed red LED light source, featuring a nominal range of 8 meters and an actual range of 7.5 meters. It includes a polarization filter and utilizes a yellow LED for light indication and a green LED to indicate power on. This sensor does not require sensitivity adjustment and operates with a wavelength of 630 nm. It is designed to suppress reciprocal influence and ensures precise alignment with an optical axis of less than 1°. The response and release time is less than 0.49 ms. It operates within a voltage supply range of 10 to 30 VDC, with a typical current consumption of 30 mA and a maximum of 40 mA. The voltage drop is less than 3 VDC. The output function is light operate with a push-pull output circuit and can handle an output current of 100 mA. It includes short circuit and reverse polarity protection. The sensor's dimensions are 18 mm in width, 45 mm in length, and 32 mm in depth, with a rectangular design made from plastic materials (ASA, PMMA) and a PMMA front optics. It connects via an M12 4-pin connector and operates in temperatures ranging from -25 to +60 °C. The sensor is rated IP 67 for protection against ingress.
- Type:
- Retro-reflective sensor
- Light source:
- Pulsed red LED
- Actual range Sb:
- 7.5 m
- Nominal range Sn:
- 8 m
- Polarization filter:
- Yes
- Light indicator:
- LED yellow
- Power on indication:
- LED green
- Sensitivity adjustment:
- No
- Wave length:
- 630 nm
- Suppression of reciprocal influence:
- Yes
- Alignment optical axis:
- < 1°
- Response time / release time:
- < 0.49 ms
- Voltage supply range +Vs:
- 10 30 VDC
- Current consumption max. (no load):
- 40 mA
- Current consumption typ.:
- 30 mA
- Voltage drop Vd:
- <3 VDC
- Output function:
- Light operate
- Output circuit:
- Push-pull
- Output current:
- 100 mA
- Short circuit protection:
- Yes
- Reverse polarity protection:
- Yes
- Width / diameter:
- 18 mm
- Height / length:
- 45 mm
- Depth:
- 32 mm
- Design:
- Rectangular
- Housing material:
- Plastic (ASA, PMMA)
- Front (optics):
- PMMA
- Connection types:
- Connector M12 4 pin
- Operating temperature:
- -25 +60 °C
- Protection class:
- IP 67
