The Baumer O500.SP-GW1B.72CU 11096085 is a standard object detection light barrier equipped with a pulsed PinPoint LED light source with a wavelength of 630 nm. It features a background position from 60 to 600 mm and a scanning range of 90% to 85% of the background position. The device offers quick response and release times of less than 0.49 ms, and operates within a voltage supply range of 10 to 30 VDC. It includes a green LED for power indication and a yellow LED for light indication. Sensing distance can be adjusted via qTeach or externally. The unit is designed with push-pull output circuitry and can handle an output current of 100 mA. It includes safety features such as short circuit and reverse polarity protection. The sensor's housing is made from durable plastic (ASA, PMMA) with a PMMA front optics, and it connects via a 4-pin, 2-meter cable. This model is IP67 rated for protection against dust and water ingress and can operate in temperatures ranging from -25 to +60 °C.
- Type:
- Light barrier
- Version:
- Standard object detection
- Background position Sde:
- 60 600 mm
- Scanning range Sa:
- 90% ... 85% Sde
- Power on indication:
- LED green
- Light indicator:
- LED yellow
- Sensing distance adjustment:
- qTeach / external
- Suppression of reciprocal influence:
- Yes
- Alignment optical axis:
- < 1°Light source=Pulsed PinPoint LED
- Wave length:
- 630 nm
- Response time / release time:
- < 0.49 ms
- Voltage supply range +Vs:
- 10 30 VDC
- Current consumption max. (no load):
- 40 mA
- Current consumption typ.:
- 30 mA
- Voltage drop Vd:
- <3 VDC
- Output function:
- Light / dark operate
- Output circuit:
- Push-pull
- Output current:
- 100 mA
- Short circuit protection:
- Yes
- Reverse polarity protection:
- Yes
- Width / diameter:
- 18 mm
- Height / length:
- 45 mm
- Depth:
- 32 mm
- Design:
- Rectangular
- Housing material:
- Plastic (ASA, PMMA)
- Front (optics):
- PMMA
- Connection types:
- Cable 4 pin, 2 m
- Protection class:
- IP 67
- Operating temperature:
- -25 +60 °C
