Baumer OADM 12I7430/S35A?í?í?í?í?í?í?í?í?í?í?í?í?í?í?í?í?í?í?í?í?í?í 11136815
Baumer
$2,808.00
The Baumer OADM 12I7430/S35A is a high-precision optical distance sensor with a measuring range of 16 to 26 mm and a beam diameter of 0.5 to 0.2 mm. It features Teach-in adjustment via a button or external control, with a minimum Teach-in range of 1 mm. The sensor is equipped with a green LED for power indication and a red LED to signal a soiled lens. It offers a resolution of 2 to 5 µm and a linearity error of ±0.013 to 0.025 mm. The sensor uses a pulsed red laser diode with a wavelength of 650 nm and is classified as a Class 1 laser, ensuring safety in operation. It has a fast response time of 2 to 3 ms and operates on a voltage supply range of 12 to 28 VDC. The output signal is analog, ranging from 4 to 20 mA, and it includes features like short circuit and reverse polarity protection. The compact, rectangular design measures 12.4 mm in width, 37 mm in height, and 34.5 mm in depth, with a die-cast zinc housing and glass optics. It offers an IP67 protection class, making it suitable for harsh environments, and can operate in temperatures from 0 to +50 °C. The sensor is designed to resist ambient light up to 50 kLux and has a connection via an M8 4-pin connector.
- Measuring distance Sd:
- 16 26 mm
- Beam diameter:
- 0.5 0.2 mm
- Adjustment:
- Teach-in: button / external
- Teach-in range min.:
- > 1 mm
- Power on indication:
- LED green
- Soiled lens indicator:
- LED red
- Resolution:
- 2 5 µm
- Linearity error:
- ± 0.013 0.025 mm
- Beam type:
- Point
- Interference suppression:
- < 30 ms
- Temperature drift:
- < 0,04 % Sde/KLight source=Pulsed red laser diode
- Wave length:
- 650 nm
- Laser class:
- 1
- Response time / release time:
- 2 3 ms
- Voltage supply range +Vs:
- 12 28 VDC
- Current consumption max. (no load):
- 100 mA
- Output circuit:
- Analog
- Output signal:
- 4 ... 20 mA
- Load resistance:
- < (+Vs - 6 V) / 0,02 A
- Short circuit protection:
- Yes
- Reverse polarity protection:
- Yes, Vs to GND
- Width / diameter:
- 12.4 mm
- Height / length:
- 37 mm
- Depth:
- 34.5 mm
- Design:
- Rectangular
- Housing material:
- Die-cast zinc
- Front (optics):
- Glass
- Connection types:
- Connector M8 4 pin
- Ambient light immunity:
- < 50 kLux
- Protection class:
- IP 67
- Operating temperature:
- 0 +50 °C
