The Baumer OADM 13T7580/S35A 11043127 is a high-precision laser distance sensor designed for versatile applications requiring a measuring distance of 50 to 550 mm. It features RS232 adjustment for easy configuration and a green LED for power indication. The sensor offers a resolution between 90 and 1150 µm and maintains linearity error within ±0.3 to 3.5 mm. Equipped with a pulsed red laser diode with a wavelength of 650 nm, it falls under Laser class 2, ensuring safe operation. The response time is less than 2 ms, making it suitable for fast-paced environments. It operates on a voltage supply range of 12 to 28 VDC and has a maximum current consumption of 80 mA with no load. Additional features include short circuit and reverse polarity protection, an alarm indicator via a red LED, and a robust aluminum housing with glass optics. The sensor is IP67 rated, indicating high resistance to dust and water, and can operate in temperatures ranging from 0 to +50 °C. It connects through an M8 4-pin connector, ensuring reliable and secure connections.
- Measuring distance Sd:
- 50 550 mm
- Adjustment:
- RS232
- Power on indication:
- LED green
- Resolution:
- 90 1150 µm
- Linearity error:
- ± 0.3 3.5 mm
- Beam type:
- Line
- Beam width:
- 2 mm
- Beam height:
- 4 13 mm
- Alarm indicator:
- LED red
- Temperature drift:
- < 0,07 % Sde/KLight source=Pulsed red laser diode
- Wave length:
- 650 nm
- Laser class:
- 2
- Response time / release time:
- < 2 ms
- Voltage supply range +Vs:
- 12 28 VDC
- Current consumption max. (no load):
- 80 mA
- Output circuit:
- RS232
- Short circuit protection:
- Yes
- Reverse polarity protection:
- Yes, Vs to GND
- Width / diameter:
- 13.4 mm
- Height / length:
- 48.2 mm
- Depth:
- 40 mm
- Design:
- Rectangular
- Housing material:
- Aluminum
- Front (optics):
- Glass
- Connection types:
- Connector M8 4 pin
- Ambient light immunity:
- < 100 kLux
- Protection class:
- IP 67
- Operating temperature:
- 0 +50 °C
