The Baumer OM70-L1000.HV0700.VI 11200095 is a high-precision distance measuring sensor designed for industrial applications. It features a measuring distance of 100 to 1000 mm and a measuring range of 900 mm, with a sweet spot at 700 mm. The device offers high resolution (3 to 63 µm) and repeat accuracy (1 to 32 µm), ensuring reliable measurements. It includes a touch display and RS485 for easy adjustment, along with LED indicators for power and output status. The sensor uses a pulsed red laser diode with a wavelength of 660 nm and operates within a laser class of 2. It supports a high measuring frequency of 2500 Hz and has a quick response delay of 0.8 ms. The sensor is equipped with both analog and RS485 output circuits, providing versatile connectivity options. It is built to withstand harsh environments with IP67 protection and can operate in temperatures ranging from -10 to +50 °C. The robust aluminum housing and glass optics are designed to handle vibrations and shocks as per IEC standards. This sensor is ideal for precise distance measurement in complex industrial settings.
- Type:
- Distance measuring
- Version:
- OM70 laser line
- Measuring distance Sd:
- 100 1000 mm
- Measuring range Mr:
- 900 mm
- Sweet spot:
- 700 mm
- Adjustment:
- Touch Display, RS485
- Power on indication:
- LED green
- Output indicator:
- LED yellow / LED red
- Resolution:
- 3 63 µm
- Repeat accuracy:
- 1 32 µm
- Linearity error:
- ± 0.19 % Mr
- Beam type:
- Line
- Temperature drift:
- 0,065 % Sde/K
- Hysteresis digital output:
- AdjustableLight source=Pulsed red laser diode
- Wave length:
- 660 nm
- Laser class:
- 2
- Response delay:
- 0.8 ms
- Measuring frequency:
- 2500 Hz
- Voltage supply range +Vs:
- 15 28 VDC
- Current consumption max. (no load):
- 75 mA
- Output circuit:
- Analog and RS 485
- Output signal:
- 4 ... 20 mA / 0 ... 10 VDC
- Output current:
- 100 mA
- Switching output:
- Push-pull
- Short circuit protection:
- Yes
- Reverse polarity protection:
- Yes, Vs to GND
- Width / diameter:
- 26 mm
- Height / length:
- 74 mm
- Depth:
- 55 mm
- Design:
- Rectangular, front view
- Housing material:
- Aluminum
- Front (optics):
- Glass
- Connection types:
- Connector M12 8 pin
- Weight:
- 130 g
- Ambient light immunity:
- < 100 kLux
- Protection class:
- IP 67
- Operating temperature:
- -10 +50 °C
- Vibration (sinusoidal):
- IEC 60068-2-6:2008 1 mm p-p at f = 10 - 55 Hz, duration 5 min per axis 30 min endurance at f = 55 Hz per axis
- Shock (semi-sinusoidal):
- IEC 60068-2-27:2009 30 g / 11 ms, 6 jolts per axis and direction
