The Baumer OXM100-R05V.001 is a versatile laser measurement sensor equipped with multiple measuring modes including height, line/angle, area, edge, width/gap, and more. It offers a measurement range of 50 mm and a clearance distance of 100 mm, with a working range of 100 to 150 mm. The sensor provides a field of view between 48 and 72 mm and delivers high-resolution measurements with a resolution of 80 to 120 µm in X direction and 16 to 30 µm in Z direction. It achieves a repeat accuracy of 8 µm and a linearity deviation of ±0.2% MR. Designed for precision, it operates at a temperature drift of ±0.08% Sde/K and features a laser class 1 with a red wavelength of 660 nm. The sensor's light point is shaped into an 80 mm line length and a 200 µm line width at the reference distance. It supports various output signals and has dual switching outputs. The robust design includes a die-cast zinc case and a PMMA front cover, measuring 36 mm x 80 mm x 70 mm and weighing 450 g. Connectivity options include an M12 12-pin A-coded male electrical connection and a USB-C port for parameterization.
- Type:
- Measuring mode (M): Height, Line/Angle, Area, Edge, Width/Gap, Intensity Edge, Circle, Caliper Z, Caliper X, Caliper Distance, Angle Gauge, Profile in x-z
- Measurement range MR:
- 50 mm
- Clearance distance:
- 100 mm
- Working range (Sdc ... Sde):
- 100 ... 150 mm
- Reference distance:
- 125 mm
- Field of view (@Sdc ... Sde):
- 48 ... 72 mm
- Resolution X (@Sdc ... Sde):
- 80 ... 120 µm
- Profiles per second:
- 200 ... 500 Hz
- Profile points:
- 575 pixel
- Resolution Z (@Sdc ... Sde):
- 16 ... 30 µm
- Repeat accuracy Z:
- 8 µm
- Linearity deviation Z:
- ± 0.2 % MR
- Temperature drift:
- ± 0.08 %Sde/KLaser class=1
- Laser wavelength:
- Red (660 nm)
- Max. laser power:
- 2.4 mW
- Light point shape (at reference distance):
- Line Length (x) 80 mm Line Width (z) 200 µm
- Voltage supply range +Vs:
- 18 ... 30 VDC
- Analog output signal:
- 4-20mA, 2-10mA, 0-10V, 0-5V
- Switching outputs:
- 2 x Outputs (Push-Pull)
- Power supply:
- typ. 2.4W (100 mA max at 24 V)
- Electrical connection:
- M12, 12-pin, A-coded, male
- Ethernet connection:
- USB-C for parametrisation
- Trigger input specification:
- Low Level: < 2.5 V High Level: 8 V ... +Ub
- Material:
- Case: Die-cast zinc, Front Cover: PMMA
- Dimensions (W x H x D):
- 36 mm x 80 mm x 70 mm
- Width:
- 36 mm
- Height:
- 80 mm
- Depth:
- 70 mm
- Weight:
- 450 g
- Datasheet:
- View
- Operating Manual:
- View
