Baumer

Baumer RR30.DAF0-GGPI.9VF/E029 11220109

(No reviews yet) Write a Review
SKU:
11220109
Condition:
New
Scanning range Sd:
0.2 … 6 m
Scanning range close limit Sdc:
0.2 … 6 m
Scanning range far limit Sde:
0.2 … 6 m
Version:
IO-Link dual channel
Repeat accuracy:
2 mm
Response time ton:
< 40 ms
Release time toff:
< 40 ms
Temperature drift:
<± 10 mm (Full Scale)
Power-up drift:
Compensated after 20 min.
Adjustment:
IO-Link
Light indicator:
LED yellow
Power on indication:
LED green
Carrier frequency:
122 … 123 GHz
Band width:
1 GHz
Range resolution:
500 mm
Hysteresis typ.:
5 % Sde
Linearity error:
± 10 mm
Modulation type:
FMCW
Transmitting power (EIRP):
< +20 dBm
Aperture angle:
12 °
MTTF:
> 126 years
Approvals/certificates:
Ecolab FCC / CFR-47 part 15 (USA) RSS-210 Issue 10 (Canada) EN 305 550-1 V.1.2.1 (European Union) EN 305 550-2 V.1.2.1 (European Union)
Voltage supply range +Vs:
12 … 30 VDC
Current consumption max. (no load):
200 mA
Baud rate:
230.4 kBaud (COM 3)
Short circuit protection:
Yes
Reverse polarity protection:
Yes, Vs to GND
Output circuit:
IO-Link / push-pull
Output current:
100 mA 50 mA (out 2)
Voltage drop Vd:
<2.5 VDC
Design:
Cylindrical threaded
Housing material:
Stainless steel 1.4404 (V4A)
Width / diameter:
30 mm
Height / length:
97 mm
Connection types:
Connector M12
Operating temperature:
-40 … +65 °C
Storage temperature:
-40 … +85 °C
Protection class:
IP 68/69K & proTect+
Datasheet:
View
Operating Manual:
View
$1,799.00

Description

The Baumer RR30.DAF0-GGPI.9VF/E029 11220109 is a high-performance sensor with a scanning range of 0.2 to 6 meters and features IO-Link dual channel technology for precise communication. It offers a repeat accuracy of 2 mm and a quick response and release time of less than 40 ms. The sensor is designed to minimize temperature and power-up drifts, ensuring reliable operation after a 20-minute warm-up period. It includes a yellow LED for status indication and a green LED to signal power on. Operating on a carrier frequency of 122 to 123 GHz with a 1 GHz bandwidth, it provides a range resolution of 500 mm and maintains typical hysteresis of 5% at the far limit of its scanning range. The sensor's linearity error is maintained within ±10 mm, and it uses FMCW modulation with a transmitting power of less than +20 dBm. The aperture angle is 12 degrees, and it boasts an impressive MTTF of over 126 years. Certified with multiple international standards, it operates on a 12 to 30 VDC power supply and features short circuit and reverse polarity protection. The cylindrical stainless steel housing measures 30 mm in diameter and 97 mm in length, ensuring durability and compliance with IP 68/69K & proTect+ standards for high-level protection against environmental conditions. The sensor is equipped with an M12 connector for easy installation and operates effectively in temperatures ranging from -40 to +65 °C.
