The Baumer U300.TA0-ZZZX.72CU is an ultrasonic sensor designed as an emitter with a scanning range of 0 to 1000 mm and operates at a sonic frequency of 310 kHz. It features a green LED power indication and is powered by a 12 to 30 VDC supply, consuming a typical current of 25 mA. The sensor includes short circuit and reverse polarity protection, ensuring reliable operation. It has a rectangular plastic housing made from ASA and PMMA, measuring 12.9 mm in width, 32.2 mm in height, and 23 mm in depth. The sensor connects via a 4-pin, 2-meter cable and operates within a temperature range of -25 to +65 °C, with a storage temperature range of -40 to +75 °C. It is rated IP 67 for protection against dust and immersion in water, making it suitable for harsh environments. For more details, refer to the datasheet [here](https://www.baumer.com/medias/__secure__/Baumer_U300.TA0-ZZZX.72CU_EN_20230324_DS.pdf?mediaPK=9065176727582).
- Emitter / receiver:
- Emitter
- Scanning range Sd:
- 0 1000 mm
- Scanning range far limit Sde:
- 0 1000 mm
- Sonic frequency:
- 310 kHz
- Power on indication:
- LED green
- Voltage supply range +Vs:
- 12 30 VDC
- Current consumption typ.:
- 25 mA
- Residual ripple:
- < 10 % Vs
- Short circuit protection:
- Yes
- Reverse polarity protection:
- Yes, Vs to GND
- Design:
- Rectangular
- Housing material:
- Plastic (ASA, PMMA)
- Width / diameter:
- 12.9 mm
- Height / length:
- 32.2 mm
- Depth:
- 23 mm
- Connection types:
- Cable 4 pin, 2 m
- Operating temperature:
- -25 +65 °C
- Storage temperature:
- -40 +75 °C
- Protection class:
- IP 67
- Datasheet:
- View
