The Baumer UNCK 09U6914 11011510 is a high-precision ultrasonic sensor designed for versatile applications requiring distance measurement within a range of 30 to 200 mm. It features repeat accuracy of 0.5 mm and a resolution of less than 0.3 mm, ensuring precise measurements. The sensor operates with a response and release time of less than 35 ms and has a sonic frequency of 380 kHz. It includes a Teach-in adjustment for easy setup and target indication flashing for alignment aid, along with dual-color LED indicators for operational status. The sensor is powered by a 15 to 30 VDC supply and consumes a maximum of 35 mA with no load. It offers a voltage output signal ranging from 0 to 10 V or 10 to 0 V and supports an output current of 15 mA. Enhanced features include short circuit and reverse polarity protection, ensuring robust performance. The compact, rectangular housing is made from durable PA 12, measuring 8.6 mm in width, 55 mm in height, and 24.5 mm in depth, and is connected via a 2-meter PUR cable. Suitable for operating temperatures from 0 to +60 °C, the sensor is IP 67 rated, indicating a high level of protection against dust and water ingress.
